Get to Know ScreenFloat 2 – Part III: Float – Picture-in-Picture for your Screenshots and Recordings

Let’s take a tour through ScreenFloat and see how it can power ^up your screenshots, too.

ScreenFloat powers up your screenshots by allowing you to take screenshots and recordings that float above everything else, keeping certain information always in sight. Its Shots Browser stores your shots and helps you organize, name, tag, rate, favorite and find them. Everything syncs across your Macs.
Extract, view and copy detected text, faces and barcodes. Edit, annotate, markup and redact your shots effortlessly and non-destructively. Pick colors any time. And more.

Posts in this Series

Part I	Hello ScreenFloat
Part II	Capture – Take Screenshots and Record Your Screen
Part III	Float – Picture-in-Picture for your Screenshots and Recordings
Part IV	Edit – OCR, Annotate, Crop, Fold, Resize, Rotate, Trim, Cut and Mute
Part V	Share – Drag and Drop, Link Sharing, Export
Part VI	Store – The Shots Browser, iCloud Sync, Tags Browser
Part VII	Integrate – Widgets, Siri Shortcuts, AppleScript, Workflows, Spotlight

Part III: Float – Picture-in-Picture for your Screenshots and Recordings

A floating screenshot or recording can help you remember something, copy information over from one app to another, or have reference material visible. It’s also the fastest way to markup, redact, and extract information from shots.

Sometimes, you don’t want to copy just one line, or all text – you want to copy different, non-consecutive lines out of the shot, without having to go back and forth between copying and pasting.
This is what ScreenFloat’s Append-Copy is for:
Right-click the lines you want to copy, hold down the option (⌥) key on your keyboard and select Append-Copy to copy multiple lines so you can paste them all together at once:

^{Copying multiple, non-consecutive lines out of a shot for one, smooth paste operation.}

Viewing Barcodes

ScreenFloat can handle all sorts of barcode content, like vCards, Calendar Events, URLs, and more.
Like Text, Barcodes appear in the Detected Data submenu, for you to access all of them at once:

Like text, you can right-click specific barcodes for direct access so you can Quick Look them, etc.

Convenience Feature: When you only capture a barcode, ScreenFloat will figure you’re interested in its contents, so it pops up the relevant menu automatically:

QuickSmart-Redactions

There’s a chance you might want to remove sensitive information before sharing a screenshot. One way to do that would be to Annotate the image in ScreenFloat and redact manually.
But there’s a quicker way. A smarter way. The QuickSmart way ^{(see what I did there?)} !

Right-click a line of text, a barcode, or a face, and you’ll have the option to redact it right there:

^{QuickSmart-Redacting a QR code, two lines of text, and a face.}

Redactions are non-destructive and can always be changed or removed. You can do so by choosing Annotate from the menu.

The kind of redaction used (color-block-out, pixellate, blur) depends on the default you have set for the Redaction tool in Annotations. By default, it’s color-block-out (because it’s the safest method). To change it to pixellate, like I have, choose Annotate and double-click the Redaction tool. Select your preferred method in the popover, making it the new default for redactions you make manually in Annotate, as well as QuickSmart redactions.

Copying text or viewing barcodes is also available in paused screen recordings. Redactions/Annotations are only available for screenshots at this time.

Floating Shot Visibility

Move and resize floating shots just like you would any other window: drag them around your screen to move, grab a corner or edge and drag it inwards or outwards to resize.

Floating shots can also be closed, by pressing the x button at the top left. The shot will remain in your Shots Browser, where you can access and re-float it at any time.

Hiding and Unhiding Shots

Shots can also be hidden. This closes the shot, too, but keeps it around so you can quickly show it again without having to go through the Shots Browser. With a keyboard shortcut (by default control (^) – option (⌥) – command (⌘) – H), or from ScreenFloat’s menu bar icon, you can toggle all currently visible floating shots between hidden and unhidden.

This is perfect for situations where shots might cover parts of your screen you need to get to without moving stuff around, or when you know you don’t need shots right now, but will soon, or repeatedly, even.

Hide a single shot by hovering over its close button, or by right-clicking it.

^{^{Hover your mouse cursor over the close button to reveal more options}}

Unhide individual shots from ScreenFloat’s menu bar icon:

Pin Shots to Spaces

If you don’t want a shot to follow you around as you move between spaces and fullscreen apps, you can pin to the current space: right-click it and select Visibility > In Current Space. Now it will remain on that space, until you set it to follow you again, or if you relaunch ScreenFloat.

Pin Shots to a Apps

Shots you require to be visible only in a certain app can be pinned to that app.
This will automatically hide the shot if the selected app is not frontmost, and show it when it is:

^{Changing a floating shot’s visibility to “Currently Active App”, so it’ll only be visible when the Finder is active.}

Opacity Scrolling, Ignore Mouse Clicks

Scroll up and down on a floating shot to change its opacity – very useful for revealing what’s underneath, for example, when trying to compare two versions of something.

Speaking of which, you can make floating shots temporarily ignore all mouse input so you can click and drag through them – perfect for drawing through a shot, for instance.

^{Changing a floating shot’s opacity, making it ignore mouse input, and drawing through it.}

To make the shot accept mouse input again, click on its info panel at the bottom.

If you have a couple of floating shots ignoring mouse clicks, that info panel at the bottom could be distracting. Click on the chevron and select Hide Info Panel, to hide it for all currently floating mouse-click-ignoring shots.

With the info panel gone, you might wonder how to make Shots accept mouse clicks again: click ScreenFloat’s icon in your menu bar and select Stop Ignoring Mouse Clicks:

Work Mode

If you find your floating shots get in your way too often, you can use ScreenFloat’s “Work mode”, which you can activate in Settings > Floating Shots.
With it enabled, floating shots temporarily disappear when you move your mouse cursor over them, and reappear as you move away.

Alternatively to having Work Mode always active, temporarily toggle it by holding down the command (⌘) key on your keyboard as you mouse over.

Color Picker

Floating shots come with a handy color picker. Option (⌥) – click-and-drag anywhere on a floating shot and the picker will pop up.

^{Picking a color from a floating shot, dragging the resulting color onto a selected line of text to change its color.}

Release the mouse button when you’re at the color you want to pick. A menu will appear, allowing you to copy the color’s hex-, RGB-, float-, or hsl values, or a sample color image. You can even drag it onto a target in another app, making it easy to use the color right away.
Recently picked colors are saved for you to access from the picker menu itself, or ScreenFloat’s widgets (which we’ll talk about in a later installment of this blog series).

If you’re using a Magic Mouse, you can adjust the color picker’s “crosshair” on the fly by scrolling up or down while you’re picking colors. If not, you can adjust the size in ScreenFloat’s settings.

Edit and Annotate Shots

We’ll talk about this in more detail in the next installment of this series, but for now, here’s a short overview of the changes you can make to shots and recordings:

Screenshots

Crop and “Fold”
Rotate
Resize/Scale
Reduce the shot’s resolution (from a “retina” dpi of 144 or more to 72 dpi)
Annotate/Markup
- Freedraw
- Lines
- Ovals
- Rectangles
- Arrows
- Stars
- Checkmarks
- X-marks
- Text
- Smart numbered lists
- Highlight
- Redact (block, pixelate, blur)
  ^{Markup is non-destructive, so you can always come back later and make changes, or remove them.
  If you’re using Sidecar with an iPad, ScreenFloat supports the Apple Pencil’s double-tap to switch through the different tools.}

Screen Recordings

Crop
Rotate
Resize/Scale
Trim
Cut video
Remove (individual or all) audio tracks

Drag and Drop Sharing

Probably nothing is more important than being able to share screenshots and recordings. That’s why in ScreenFloat, it’s extra easy, and extra powerful at the same time.

Drag the little document icon of a floating shot and you’ll be able to drag the shot as-is anywhere you wish. Alternatively, you can long-press-and-drag, if you prefer (or if the document icon is off-screen).

If you require a certain file format, however, or if you want to reduce the shot’s resolution or dimensions before dragging it somewhere, click the document icon instead, and all sorts of options will become available to you:

Change the file format (PNG, JPEG, TIFF, PDF, HEIC)
Reduce the resolution (from 144+ “retina” dpi to 72 dpi)
Resize the image (by longest/shortest side, or width/height)
Whether markup and annotations should be included in the dragged file, or just the original image should be shared
Whether notes and tags should be included as EXIF and Finder metadata

Click any of the file format options to set it as your default for quick-dragging, should you prefer, say, JPEG over PNG files for sharing.

We’ll talk more about sharing options in a future part of this series.

The “Action” Menu

Right-click any floating shot, or click on the little gear icon in the top right to access the “Action” menu. It contains everything you need for working with your shots.

Some of these we’ll talk about in more detail in a future installment of this series, so for now, let’s go over all of them and see what they do.

Detected Data ^{(not shown in the screenshot above)}
When you right-click onto a text line, a face or barcode directly, you’ll have the option to view, copy or redact it easily with this (see above)

Share

Copy: Allows you to copy the PNG/MOV file of the shot, or in case of screenshots, the image data in different formats
- Note: Hold down option (⌥) to change this to Duplicate, allowing you to duplicate the floating shot
Extract Still Image From Video ^{(recordings only; not shown in the screenshot above)}: Extract the current frame from the video into a new shot, or copy it to the clipboard
Open Copy With: Open a copy of the shot with a compatible app
Share: Your standard share menu, with the additional option of uploading the shot to iCloud and sharing a link to it, instead of a potentially large file.
Detected Data: Offers you to view, copy and redact all or individual text lines, barcodes and faces.
Export…: Export the shot to a folder of your choice, into different file formats, quality, and more

Edit

Edit Info… : Edit the title, notes and tags of the shot (useful in the Shots Browser)
Resize… : Resize/scale the shot, and/or reduce its resolution
Rotate: Rotate the shot (counter-)clockwise
Trim Video ^{(recordings only; not shown in the screenshot above)}: Trim the video’s beginning and end
Cut Video ^{(recordings only; not shown in the screenshot above)}: Cut the video, or its individual audio tracks
Remove Audio ^{(recordings only; not shown in the screenshot above)}: Remove the video’s audio tracks (all, or individually)
Annotate… : Add annotations, redactions and markup to the shot (coming in the next installment)
Re-capture and Delete… : Allows you to re-capture the area of this shot was captured in, then deletes the original
- Note: Hold down option (⌥) to change this to Capture Shot Again, which allows you to capture that shot’s screen area again without deletion

Organize

Add to Favorites: Favorite the shot (useful in the Shots Browser, Widgets)
Add to: Add the shot to an existing or new folder in the Shots Browser
Rating: Rate the shot from between 0-5 stars (useful in the Shots Browser, Widgets)
Show in Shots Browser: Opens the Shots Browser and selects and reveals this shot
Settings…: Open ScreenFloat’s settings

Visibility

Ignore Mouse Clicks: makes the shot temporarily ignore mouse input (see above)
Visibility: Make this shot appear everywhere, only in the current space, or only when the current app is active (see above)
Hide Shot: Hides this shot, so it disappears, but you can recall it quickly from ScreenFloat’s menu bar icon (see above)
Close Shot: Closes the Shot to the Shots Browser

^{Note: Hold down the option (⌥) modifier on your keyboard to make the visibility setting apply to all floating shots, or option (⌥) and function (fn) to make them apply to all floating shots on that screen.}

Double-Click Workflows

For things you find yourself doing repeatedly, you can use double-click workflows.
For instance, if you find yourself always reducing a shot’s resolution before you mail it to somebody, set up a double-click workflow for it, to automate the process. Now you only have to double-click the floating shot and its resolution will be reduced, and then attached to a new eMail, all in one fell swoop.

^{Double-clicking the floating shot rotates it clockwise and then opens a new mail message with it, thanks to a custom double-click workflow.}

We’ll talk more about these workflows in a future installment of this series – there are a lot of options available.

Up Next

The next part of this series – Part IV: Edit – OCR, Annotate, Crop, Fold, Resize, Rotate, Trim, Cut and Mute – takes a detailed look at all the Editing, Markup and Redaction options available.
